BFRT-5MPW28-S

"NDAA COMPLIANCE" 2.8 MM HD 5MP TVI DAY/NIGHT WEATHERPROOF IR Built in Mic FIXED LENS BULLET CAMERA

Categories:

● 5 MP CMOS image sensor
● High Performance 5MP Resolution
● Compatible with 5MP TVI, 4MP TVI, Analog
● UTC, OSD, WDR, 3D DNR, Smart IR, Built in Mic
● Wide Angle 2.8mm Fixed Lens
● 18 Built in IR LEDs, (75 Ft. Night Vision)
● Vandal Resistant IP66 Weatherproof
● True Day/Night
● 3 Years Warranty

Technical Specifications
Model No.	BFRT-5MPW28-S
Camera
Image sensor	1/2.7“ Progressive Scan CMOS
Min. illumination	0.01 Lux @ (F1.2,AGC ON),0 Lux with IR /0.014 Lux @ (F1.4,AGC ON),0 Lux with IR
Shutter time	1 / 25 s to 1 / 50,000 s
Lens	2.8mm Angle of View: 90.9°
Lens mount	M12
Day & night	ICR
Digital noise reduction	3D DNR
Wide dynamic range	DWDR
Synchronization	Internal synchronization
HD Video Output	1 Analog HD ouput Yellow
Video	Compatible with 5MP TVI, 4MP TVI, Analog
S/N Ratio	More than 52dB
Max. Image Resolution	2592 (H) × 1944 (V)
Signal System	NTSC
Frame rate	5MP@20fps
Image settings	Saturation, brightness, contrast, sharpness adjustable through client software or web browser
BLC	Supported
General
Operating conditions	(-22°F ~ 140 °F) humidity 90% or less (non-condensing)
Power supply	12 VDC
Power consumption	Max. 4W
Weather proof rating	IP66
IR range	Up to 75 Feet
Dimension	φ70×149.5 mm (φ2.76” ×5.89”
Weight	360 g (0.79 lb)
