Physical
System: Linux	Door Entry: IC (13.56MHz) & ID (125kHz) card
RAM: 64 MB	Reset Button:1
ROM: 128 MB	RS485 Port: 1
Front Panel: Aluminum	Relay Out: 2
Power Supply: PoE (802.3af) or DC 12V/2A	Input: 2
Standby Power: 1.5 W	IP / IK Rating: IP65 / IK08
Rated Power: 3.5 W	Installation: Surface Mounting
Camera: 2MP, CMOS	Surface Mounting DIM: 188 x 88 x 34 mm
Indicator Light: 3	Working Temperature: -40℃ to +55℃
Wiegand Port: Support	Storage Temperature: -40℃ to +70℃
Ethernet Port: 1 x RJ45, 10/100 Mbps adaptive	Working Humidity: 10% to 90% (non-condensing)
Audio	Networking
Audio Codec: G.711	Protocol: ONVIF, SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP
Echo Cancellation
DTMF: RFC2833
Microphone: Built-in microphone
Speaker: Built-in speaker
Video	Package Features
Video Codec: H.264	Package Content:
Video Resolution: 1280 x 720	S213M (Power adapter not included)
Viewing Angle: 110°(H) / 60°(V) / 125°(D)	Bracket
Max. Image Transfer Rate: 720p – 25fps	Screwing Kit
Light Compensation: LED white light	Quick Start Guide
	Qty/CTN: 12 pcs
	N.W/PCS: 0.78 kg
	G.W/CTN: 12.00 kg/12.78 kg
	Giftbox Size: 237 x 147 x 92 mm
	Carton Size: 580 x 500 x 170 mm

S213M-Quick-Start-Guide_V1.2 S213M-User-Manual_V1.3

S213M Spec Sheet
