IPC-PTZ-20X5MPIRW-WL
2 reviews
Discontinued
"NDAA COMPLIANCE" 5MP FULL COLOR NETWORK 20X SPEED DOME
● HD 5MP Resolution
● 20x Optical Zoom. 4.7-94MM
● H.265+ H.264+ Ready, H.264. MJEPG
● 8 Built in Warm Light LEDs, (300 ft, FULL COLOR)
● Priavcy Masking, 3D DNR, DWDR
● PoE Support Plug in and Play
● IP66 Rating
● Full Color Day & Night
● 3D Inteligent Positioning
| Technical Specifications | |
| Model No. | IPC-PTZ-20X5MPIRW-WL |
| Camera | |
| Image sensor | 1/2.5" Progressive CMOS |
| Image Resolution | 2594x1944 |
| Signal System | PAL/NTSC |
| Min Illumination | 0.02 Lux Full Color Day & Night |
| White Balance | Auto/Manual/ATW/Indoor/Outdoor |
| AGC | Auto/Manual |
| S/N Ratio | > 50 db |
| 3D DNR | Support |
| DWDR | Support |
| EIS | Support |
| Backlight Compensation | Support |
| Shutter Speed | NTSC: 1-1/10,000s |
| Day & Night | Full Color Day & Night |
| Optical Zoom | 20X |
| Privacy Mask | 8 Privacy Mask, Max 8 Zones can be masked simultaneously |
| Focus Model | Auto/Manual |
| Lens | |
| Focal Length | 4.7-94mm |
| Zoom Speed | Approx. 3s |
| Angle of View | 63.2-3.9 Degree |
| Min Working Distance | 10mm(W)-1000mm(T) |
| Pan and Tilt | |
| Pan Range | 360°Endless |
| Pan Speed | 45°/s |
| Tilt Range | 0°- 90°(Auto Flip) |
| Tilt Speed | 30°/s |
| Number of Preset Position | 256 |
| Patrol | 8 Patrols, Up to 32 Presets per patrol256 |
| Pattern | 4 Patterns, with total recording time no less than 10 mins |
| Power-off Memory | Support |
| Park Action | Preset/Patrol/Pattern/Pan Scan/Tilt Scan/Random Scan |
| PTZ Position Display | On/Off |
| Color Mode | |
| Warm Light | 8 Warm Lights |
| Light Distance | 300 Ft |
| Light Intensity | Auto adjusted |
| Network | |
| Onvif | Support |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, |
| Dual Streams | Support |
| Security | User Authentication, Host Authentication |
| Interface | |
| Communication interface | 1 RJ45 10 M / 100 M Ethernet interface |
| User/Host level | Up to 32 users，3 Levels: Administrator, Camera control, Live view only |
| Web Browser | IE 7, IE 8, IE 9 |
| Camera Control | Pan / Tilt, Zoom, Focus, Click centering, Drag zoom, Iris, Preset position call |
| Protocols | Self-adaptive |
| General | |
| Menu Language | English |
| Power | DC 12V 4A, Day 10W (MAX), Night 30W(MAX) |
| Working Temperature | -20°C-60°C，≤90%RH(frostless) |
| Mounting | Wall Mount Included |
| Weather proof rating | IP66, TVS 3,000V lightning protection, surge and voltage protection |
| Dimensions | 300*300*470MM |
| Weight | 3.5Kg (7.7 lbs) |
